The JBL MA510 is a professional power amplifier from JBL’s MA series, designed primarily for commercial audio applications. It is typically used in environments such as retail stores, schools, offices, and other venues that require high-quality amplification for background music, paging, and public address systems. Here’s an overview of the JBL MA510 specifications:

JBL MA510 Specifications:

General Features:

• Power Output:
  • 100 watts per channel @ 8Ω
  • 150 watts per channel @ 4Ω
  • 70V/100V: Suitable for use in commercial distributed audio systems with constant-voltage speaker wiring.
• Amplifier Type:
  • Class D: Known for its high efficiency and lower heat generation compared to traditional Class A/B amplifiers.

Input and Output:

• Inputs:
  • Balanced XLR Input: For professional-grade audio equipment, reducing noise in the signal path.
  • Unbalanced RCA Input: For consumer-level audio devices such as CD players, computers, or media players.
  • Microphone Input: Typically used for paging applications or announcements, which can override the background music.
• Outputs:
  • Speaker Outputs: Compatible with 4Ω, 8Ω, and 70V/100V systems.
  • Pre-Amp Output: Allows for connecting additional amplifiers or recording devices.

Performance Features:

• Frequency Response:
  • Typically 20 Hz – 20 kHz, covering the full range of human hearing for clear and full-range sound reproduction.
• Signal-to-Noise Ratio:
  • Greater than 90 dB: Ensures minimal distortion or background noise during operation.
• Total Harmonic Distortion (THD):
  • Less than 0.05%: Ensures clean, undistorted audio output.

Control Features:

• Bass and Treble Controls:
  • ±10 dB for both bass and treble frequencies, allowing users to adjust the tonal quality for different acoustics and sound preferences.
• Master Volume Control:
  • Front-panel knob to control the overall volume of the amplifier.
• Microphone Volume Control:
  • Allows you to adjust the microphone input level independently of other audio sources.

Protection Features:

• Thermal Protection:
  • Automatically shuts down the amplifier in case of excessive heat buildup to prevent damage.
• Overload Protection:
  • Protects the amplifier from potential damage caused by excessive load or speaker impedance issues.
• Short Circuit Protection:
  • Safeguards the amplifier from damage due to short-circuits in the speaker wiring.

Cooling System:

• Active Cooling:
  • Internal cooling fan to keep the amplifier at optimal temperatures during prolonged use.

Size and Weight:

• Dimensions:
  • Typically 1U height (standard for rack-mounted units), fitting into a 19-inch rack.
• Weight:
  • Approximately 7 kg (15.4 lbs), making it portable yet robust for commercial use.

Additional Features:

• Rack-Mountable:
  • Designed to fit into a standard 19-inch rack for easy integration into professional audio systems.
• LED Indicators:
  • For power, signal, and protection status, making it easy to monitor the amplifier’s operation.
• Bus Link Input/Output:
  • Allows the unit to be connected in series with other amplifiers or audio devices for expanded system configurations.

Applications:

The JBL MA510 amplifier is suitable for various commercial audio installations, including:

• Retail Stores: Background music and in-store announcements.
• Conference Rooms and Offices: Paging and general audio amplification.
• Public Address Systems: For schools, warehouses, and other venues requiring clear announcements.
• Hotels and Restaurants: Background music and paging systems.

Conclusion:

The JBL MA510 offers robust features for commercial amplification needs. With high power output, multiple input options, and excellent sound quality, it is a versatile and reliable choice for venues that require distributed audio systems, background music, or paging. The protection features and efficient Class D design make it an excellent choice for long-term, trouble-free operation in professional environments.
