Focusrite Forte Soundcardrite

Focusrite Forte Soundcardrite

The Focusrite Forte is one of most sleek and powerful interfaces on the market, It features Focusrites high end REDNET preamps and a bright OLED screen.With 2 in and 4 out it is ideal for anyone requiring the highest quality capture with the most portable interface

Features

• Two Focusrite RedNet remote-controlled microphone preamps
• Ultra-high quality A-D and D-A conversion at up to 24-bit/192kHz resolution
• +48V phantom power, HPF and polarity reverse
• Mac and Windows compatible
• Bus-powered (except when 48V phantom power is engaged)
• Premium aluminium enclosure
• Built-in main monitor outputs do not require a breakout cable!
• Supplied breakout cable for mic and line inputs only
• Touch-sensitive buttons
• Large metal control knob
• Colour OLED (Organic LED) metering/display
• Control and configuration software included
• Focurite’s superb plug-in emulation of the classic Forte Console EQ and Compression, Midnight, is included

Forte USB Audio Interface Specifications:
Hardware Specifications

• 2 in / 4 out USB audio interface
• 192KHz, 24-bit conversion
• 2 Focusrite microphone preamplifiers
• Silver aluminium chassis
  Top panel
• Large multi-function push encoder
• 4 touch sensitive mode buttons
• Headphone socket (front panel)
  Rear panel
• 2 balanced monitor outputs – ¼” TRS Jack
• Input Loom socket
• Power socket
• USB 2.0 Port
• Kensington Lock slot (rear side)
• Key Performance Figures
• Measured Real World ADC Dynamic Range 117 dB (A-weighted)
• Measured Real World DAC Dynamic Range 118 dB (A-weighted)
• Chipset ADC/DAC Dynamic Range 120 dB (A-weighted)
  Microphone Inputs
• Gain Range 0 – 75dB
• Mic Input RedNet remote controlled pre-amplifier
• Maximum Input level @ Minimum gain for 0 dBFS (Rs = 150 Ohms, without pad) 12dBu +/- 0.5dB
• Minimum Input level @ Maximum gain for 0 dBFS (Rs = 150 Ohms, without pad) -63dBu +/- 0.5dB
• SNR (A-weighted) -117dB (Rs = 150 Ohms)
• Frequency Response (Rs = 150 Ohms) 50Hz – 42kHz +/- 0.1 dB (-0.5dB @ 20Hz)
• THD+N @ -1dBFS: 0.0007% (measured with +11dBu input, minimum gain, 1kHz with a 20Hz/22kHz bandpass filter, Rs = 150 Ohms)
• Noise EIN: 128dB (measured with 60dB of gain with 150 Ohm termination 20Hz/22kHz bandpass filter)
• Input Pad Attenuation 10dB (Rs = 150 Ohms)
• Phantom Power 48V, independently switchable for each channel (only available with external Power Supply connected)
